1. Features a Cortex-M0 32-bit microcontroller core and bus-based input for faster response.

2. Two dimension, WxH,mm: 160x80mm and 80x160mm (vertical type)

3. Both channels accept 18 different signal types, supporting simultaneous measurement, display, control, and transmission output.

4. Offers analog transmission output and RS485 communication output, facilitating easy connection to DCS, PLC, touchscreens, and other systems.

5. Supports up to eight relay outputs, with alarm setpoints independently configurable for each channel.

6. Parameter settings can be restored to factory defaults with a single-button operation.

Main Features:

• Operating Power Supply: AC/DC 85~240V (High-Voltage Version); DC24V (Low-Voltage DC Version, Custom Order Required)

• Input Signals
  When RTD or Thermocouple input is selected, the meter automatically displays ranges per national standards; parameters DOT, PL, PH will be hidden automatically by the controller.

  Input Signal	Code	Input Signal	Code
  Type T Thermocouple	t-t	Cu50   RTD	Cu50
  Type R Thermocouple	t-r	0–375Ω   Resistance	375
  Type J Thermocouple	t-J	DC   0–75mV	0-75
  Type WRe3/25 Thermocouple	t-d	DC   0–30mV	0-30
  Type B Thermocouple	t-b	DC   0–5V	5u
  Type S Thermocouple	t-S	DC   0–10V	0u
  Type K Thermocouple	t-K	DC   0–20mA	0-20
  Type E Thermocouple	t-E	DC   0–10mA	0-0
  Pt100 RTD	P00	DC   4–20mA	4-20

• Basic Accuracy Error: 0.2%FS

• Measurement Rate: 20 times per second

• Display Refresh Interval: 1 time per second

• Transmitter Excitation Output: DC24V / 200mA

• Transmitter Output Load Capacity: ≥ 500 Ω

• Transmitter Output Accuracy: 0.2%

• Communication Protocol: RS485 Modbus RTU

• Relay Contact Rating: AC250V / 3A

• Operating Environment: Temperature -10~50°C, Humidity 10~95% RH (Non-Condensing)

• Overall Dimensions & Mounting Cutout: Refer to Product Selection List
