Heavy Duty Encoders for Crane
20260408833608
Heavy Duty Encoders for Crane

Highly robust HeavyDuty mechanics, compact housing and innovative technology, works under the harshest conditions.
Heavy-duty industries such as cranes, marine equipment, and steel production demand motion control technologies that can operate reliably in extreme environments. Equipment must perform under heavy loads, continuous operation, vibration, temperature fluctuations, and exposure to dust, moisture, and corrosive conditions.
The HeavyDuty encoders for Crane provides dependable position and speed feedback that supports smooth motion control, improved load handling accuracy, and safe crane operation. Rugged designs built for outdoor and high-load environments help ensure long service life and reliable performance in demanding crane applications.

info@nietz.cn +86 13764513349 Consulta
Características


Pic

Series

Destription

Features

HDR seriesThe HDR series exhibits excellent resistance to mechanical damage and can withstand high axial and radial loads, meeting the needs of various industrial field applications and different host computer applications.

  • Die-cast metal casing, sturdy and not easily damaged.

  • Polymer grating

  • Pulse rate max up to 10 000 P/R

imageHD58N series

The HD58N series products feature a dual-bearing structure design, and the metal housing provides excellent resistance to mechanical damage, making them suitable for a wide range of industry applications. The products utilize a stainless steel through-hole shaft design with a maximum shaft diameter of 15 mm, capable of withstanding high radial and axial loads to meet the needs of various industry applications. The products employ a wide voltage range power supply design, featuring reverse connection protection and short-circuit protection, effectively reducing the impact of incorrect wiring during installation on the encoder.

  • φ8…φ15mm Wide range of shaft diameters to suit various field application needs

  • Equipped with reverse connection protection and short circuit protection to ensure safe use.

  • Pulse rate max up to 10 000 P/R

imageHDT90N seriesThe HDT90N series is designed for various heavy industrial applications and applications involving heavy loads on shafts. It features excellent resistance to mechanical damage and can withstand high radial and axial loads on shafts. The product adopts a bushing-type structure design, allowing direct mounting on the drive shaft and flexible fixing connection via crank arms or spring plates.

  • The metal casing is more robust, with a compact impact-resistant structure,  making it suitable for installation and use in confined spaces.

  • Various flexible connection methods, such as crank arms or spring plates,  ensure greater flexibility in product installation.

imageEV seriesThe EV series is specifically designed for various heavy industrial applications and applications with heavy-duty shaft loads. It features excellent resistance to mechanical damage and can withstand high radial and axial loads on the shaft. The bushing structure allows for direct mounting on the drive shaft, with flexible connections via crank arms or retaining pins. In addition to providing incremental encoder signal output, the product can also include an overspeed switch alarm output, catering to both precision control and safe production needs.protection, effectively reducing the impact of incorrect wiring during installation on the encoder.

  • Multiple accessories, softer connections, and greater flexibility

  • Integrated structural design saves installation space and costs.

  • Overspeed switch alarm output ensures safe production.

  • The electrical output has reverse connection protection and short circuit protection.

imageEX series

The magnetoelectric version is available in an economical 13×14-bit configuration, with a  maximum of 18×12-bit.

The photoelectric version has a maximum of 18 bits per single turn and 16×14 bits per multi-turn.Axial connector connection, compact structure, solid or hollow shaft (blind hole)

imageAbsolute / Incremental / Overspeed switch 3-in-1 Encoders

  • Multiple accessories, softer connections, and greater flexibility

  • Integrated structural design saves installation space and costs.

  • Overspeed switch alarm output ensures safe production.

  • The electrical output has reverse connection protection and short circuit protection.
